12 92478_UM_ SART_ F
2
TECHNICAL SPECIFICATIONS
2.1
ELECTRICAL SPECIFICATIONS
Frequency: X-band (3 cm) (9.2 - 9.5 GHz)
Temperature range: Operating: -20 to +55°C
Storage: -30 to +65°C
Radiated power: > 400 mW e.i.r.p (+26 dBm)
Sweep type: 12 sweep sawtooth type
Forward 7.5 us ±1 ms
Return 0.4 us ±0.1 ms
Starts with return sweep.
Receive sensitivity: Better than -50 dBm e.r.s.
Response delay: Max 0.5 ms
Antenna pattern: Horizontal polarization.
Omni directional radiation in the horizontal plane.
Greater than ±12.5 degrees elevation angle in the
vertical plane.
Battery: 4PCs SAFT LSH20, lithium, 4 years service life
Battery capacity: 96 hours standby +8 hours continuous operating
when activated by a radar with 1 kHz prf at -20°C.
4 years storage.
