Jøtul F 305 User Manual

3
ENGLISH
Table of contents
1.0 Technical data .........................................2
2.0 Relationship to the authorities ..................2
3.0 Safety .......................................................3
4.0 Installation ...............................................6
5.0 Daily Use ................................................12
6.0 Maintenance ...........................................13
7.0 Servicing ................................................14
8.0 Optional Extras .......................................17
9.0 Recycling ................................................17
10.0 Warranty ................................................17
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number
when contacting your retailer or
Jøtul.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoffen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certificate/
The appliance can be used in a shared flue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Serial no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Efficiency
Klasse II
Classification
Standard
Flue gas temperature
Room heater fired by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC
SP
EN
Serial no.
1.0 Relationship to the
authorities
• Installation of a fi replace must be carried out in compliance
with national laws and regulations. All local ordinances,
including those that refer to national and European
standards, must be complied with when products are
installed.
• The installation can only be put into use after it has been
checked by a qualifi ed inspector.
• Contact your local building authorities before installing a
new fi replace.
2.0 Technical data
Material: Cast iron
Finish: Black paint
Smoke outlet: Top, rear
Flue pipe dimension: Ø 150 mm
Outside air connection: Alu. fl ex - Ø 80 / Ø 100 mm
Product weight:
Burn chamber with long legs: 143 kg
Burn chamber with base: 169 kg
Soapstone top: 36 kg
Optional extras Floorplates, Ash lip, kit for
outside air connection,
protection grid for sweep
ball, short legs.
Product dimensions, distances: See Fig. 1
Technical data in acc. with EN 13240
Nominal heat output: 7 kW
Flue gas volume: 7.1 g/s
Chimney draught, EN 13240: 12 Pa
Recommended negative pressure
in smoke outlet: 14-16 Pa
Effi ciency: 79%@7.5 kW
CO emissions (13% O
2
): 0.06%
CO emissions (13% O
2
): 786 mg / Nm
3
NOx at 13% O
2
: 85 mg / Nm
3
OGC @ 13 % O
2
: 64 mg/Nm
3
Particle emission NS 3059: 1.5 g / kg
Air consumption: 6,1 litre/sec or 22 m
3
/h
Chimney temperature, EN 13240: 261
o
C
Temperature in smoke outlet: 313
o
C
Dust: <7 mg/Nm
3
@13%O
2
Type of fuel: Wood
Max. log length: 30 cm
Fuel consumption: 2.25 kg/h
Max. kindling amount: 2.4 kg
Nominal kindling amount: 1.8 kg
Operation: Intermittent
Intermittent combustion here means normal use of a fi replace,
i.e. add more fuel as soon as the fi re has burned down to
embers.

Jøtul F 305 Specifications

General

Type	Wood Stove
Material	Cast Iron
Flue Outlet	Top or Rear
Flue Size	6 inches
EPA Certified	Yes
Emissions	2.5 g/h
Heating Capacity	up to 1, 200 sq. ft.
