Jøtul F 305 User Manual

11
ENGLISH
Approval label
Jøtul F 305 with base
Fig. 11
A
B
1. Take the approval label (A) out of the ash pan and fasten
it with the nut (B), as displayed. The nut needs to be
tightened only with the fi ngers. NB: Do not cut off the
wire used for fastening the label.
4.3 Outside air connection
If external air supply is not used
Fig. 12
A
2. If external air supply is not used, the external air connector
(A) can be unscrewed, if desired. Remove the four screws
used for fastening the external air connector and then the
connector itself. (For products with base: If necessary,
you can unscrew the heat shield beneath the burn chamber
in order to facilitate the dismantling of the external air
connector.
3. Install the convection plate back in its place after removing
the external air connector.
Outside air connection through bottom
plate in base
Fig. 13
A
1. Place a cardboard plate on the back of the bottom plate
before knocking out the cover (A) with a hammer in order to
prevent the pieces from damaging something around them.

Jøtul F 305 Specifications

General

Type	Wood Stove
Material	Cast Iron
Flue Outlet	Top or Rear
Flue Size	6 inches
EPA Certified	Yes
Emissions	2.5 g/h
Heating Capacity	up to 1, 200 sq. ft.
