12
ENGLISH
Fig. 14
100
2. See the installation instructions that follow with the external
air set.
3. Attach the hose to the external air connector with a hose
clip to avoid using joints. The external air hose insulation
ends approx. 100 mm below the burn chamber.
Outside air connection through bottom
plate in base
Fig. 15
A
1. Place a cardboard plate on the back of the bottom plate
before knocking out the cover (A) with a hammer in order
to prevent the pieces from damaging something around
them.
Fig. 16
A
2. Position the bottom plate in place again.
3. Place the oven in the position where it is supposed to be.
See fi g. 1 for correct placement when it comes to safety
distances.
