Jøtul F 305 User Manual

21
ENGLISH
Fig. 40
A
9. Remove the old gasket (A) and clean the grooves. Glue
on a new gasket.
10. Install back all parts once all damaged gaskets have been
replaced.
Adjusting the door
Fig. 41
1. The door can be adjusted upwards or downwards slightly
on the door lock side by forcing it into correct position.
NB! The door cannot be fully closed when adjusting it!
8.0 Optional extras
8.1 Kit for outside air connection
Outside air connection, Ø80 mm - Cat. no. 51047509
Outside air connection, Ø 100 mm - Cat. no. 51012164
8.2 Soapstone top
Cat. no. 51048022
8.3 Ash lip for product with legs BP
Cat. no. 51047339
8.4 Protection grid for sweep ball for
Jøtul Steel Chimney
Cat. no. 151608 (Ø 150 mm)
8.5 Short legs
Cat. no. 51047318, BP
Cat. no. 51047340, WHE

Jøtul F 305 Specifications

General

Type	Wood Stove
Material	Cast Iron
Flue Outlet	Top or Rear
Flue Size	6 inches
EPA Certified	Yes
Emissions	2.5 g/h
Heating Capacity	up to 1, 200 sq. ft.
