Jøtul F 305 User Manual

8
ENGLISH
Air supply
The amount of combustion air for Jøtul’s products is approximately
20-40 m
3
/h. The outside air connection may be fi tted directly to
the Jøtul F 305 through:
• the bottom
• through a fl exible supply hose from the outside/chimney
(only if the chimney has its own duct for external air) and to
the product’s outside air connector.
Fig. 2A, through an outside wall
Fig. 2B, through the fl oor and ground plate
Fig. 2C, through the fl oor and basement
Fig. 2D, indirectly through an outside wall
4.0 Installation
NB: Check that the fi replace is undamaged before installation
begins.
NB: The product is heavy! Ensure you have help when positioning
and installing it. Make sure the product does not topple over.
NB: Do not place anything on the top plate of the stove as this
could cause permanent damage to the paint.
NB: Read the Installation and Operating instructions carefully
before installing the fi replace!
4.1 Prior to installation - Jøtul F 305
with legs
NB: There are two different legs. See the fi gure (fi g. 6) on
the bottom plate for correct placement.
Fig. 3
A
C
A
1. Remove the four transport screws (A) that fasten the oven
to the wooden pallet.
2. Leave the stove standing on the transport pallet.
3. Remove the gloves from the ash pan.
4. Lift the baffl e, ash retainer, and bag of screws out of the
burn chamber.
5. Check that the control handles (C) move freely.

Jøtul F 305 Specifications

General

Type	Wood Stove
Material	Cast Iron
Flue Outlet	Top or Rear
Flue Size	6 inches
EPA Certified	Yes
Emissions	2.5 g/h
Heating Capacity	up to 1, 200 sq. ft.
