Jovision Network Camera Quick Start Guide
5
2.2 Dome Camera Ceiling Mounting
Steps:
1. Use the screws to fix the mounting base
to the ceiling.
2. Rotate the back box counterclockwise to
secure it to the mounting base, use the lock
screw to secure the dome camera.
3. Lens angle adjustment: compare video
image on the display, adjust camera
horizontal and vertical direction by spinning
the ball, till you find the perfect angle of
areas that need to be monitored, the
installation is complete.
Notes:
Please make sure that the ceiling can support more than 50(N) Newton gravities if the camera
is fixed to the ceiling.
