Allowed relative humidity ≤ 40°C: ≤90% RH, 40-50°C: ≤60% RH
Cooling Method Convection
Altitude:
-Operating and Nonoperating 3 000 m (10 000 feet)
-Random vibration 0.31 g
RMS
from 50 - 500Hz, 10 minutes on each
axis
-Nonoperating 2,46 g
RMS
from 5 - 500 Hz, 10 minutes on each
axis
Mechanical shock in operation 50 g, 11 ms, half sine
Dimensions 199 x 98 x 40 mm
Weight 624 g
Arbitrary Waveform Generator:
Waveform Frequency Sine: 1Hz-25MHz; Square: 1Hz-10MHz;
Ramp: 1Hz-1MHz; Expon: 1Hz-5MHz
Sampling rate 250 MSa/s
Amplitude 2.5 Vpp (50Ω)/5Vpp (High impedance)
Frequency resolution 0,1 %
Channel CH1 waveform output
Waveform depth 512Sa
Vertical resolution 12 bit
Output impedance 50 Ω
Square Characteristics:
Pulse width accuracy ± 10 ns
Digital Multimeter:
Maximum resolution 4000 Counts
Testing Modes: Voltage, Current, Resistance, Capacity, Diode,
On-O
Maximum Input Voltage AC: 600 V/ DC: 600 V
Maximum Input Current AC: 10 A / DC: 10 A
