JT-UM25C
Published: 13.12.2018 Copyright by Joy-IT 14
With a right click within the voltage-current diagram further opons are available to you. Here you can
automacally scale the X-axis, copy the current data to the clipboard or export it as an Excel le, export
the current graph as an image or delete the current diagram.
1
Basic Funcons
(previous page, next page, rotate screen)
2
data sets
(Click on the corresponding data group to jump
directly to this group)
3 Main measuring interface
4 data recording interface
5 Quickcharge Interface
6 temperature overview
7
Screen brightness, me for automac
display shutdown
8 voltage-current diagram
