JT-UM25C
Published: 13.12.2018 Copyright by Joy-IT 6
3.2 MAIN MENU (MEASUREMENT RESULTS)
The values of the data groups 1-9 are stored when the power of the encoder is interrupted and are
counted again aer the encoder is switched on again.
The values in data group 0, on the other hand, ash when the meter is switched on again and are then
reset to 0.
Press and hold to rotate the display
counterclockwise.
1
Press to turn o the display. 2
Press to open the help menu. 3
Press and hold to rotate the display
clockwise.
4
Press for previous page 5
Press for next page 6
7 Voltage
8 Current
9 Accumulated electric charge
10 Accumulated energy
11 Temperature
12 Data Group
13 Equivalent resistance
14 Power consumpon
To Next Page
