3.3 QUICKCHARGE-RECOGNITION
The meter automacally detects devices with Quickcharge support. The following Quickcharge modes are
currently supported: QC2.0, QC3.0, Apple 2.4 A/2.1 A/1 A/ 0.5 A, Android DCP, Samsung
3.4 CHARGING RECORD
Aer power-up, if the current is greater than the trigger value, the system automacally starts recording
the accumulated capacity, energy and elapsed me. The "REC" indicator changes from red to green.
To set the current trigger value, press and hold to highlight the value. Press the
buon to adjust the value. The value can be set between 0.01A and 0.30A.
15 D+ (DP): Posive Data-Signal-Level
16 D- (DM): Negave Data-Signal-Level
17 Mode Display
18 Accumulated capacity
19 Accumulated energy
20 Total accumulaon me
21
Capacity / energy stascs trigger
current
22
recording indicator
Red: Recording stopped
Green: Recording in progress

Joy-it JT-UM25C Specifications

General

Brand	Joy-it
Model	JT-UM25C
Category	Measuring Instruments
Language	English
