04 05
ENEN
1. LCDdisplay
2. Leverlockforhandlebar
3. Brakehandlewithbell
4. Brakewire
5. Frontlight
6. Frontsuspension
7. Frontmudguard
8. Frontairtire
9. Sidereectors
10.Foldingsystem
11. Sidelightbelt
12. Parkingstand
13. Rearhandle
14.Rearmudguard
15. Rearlight
16.Doublerearsuspension
17. Rear air tire
18.Drumbrake
19.Motor
1.4 G Series: Technical Specifications1.3 G Series: The Main Parts
Model G5
MaxLoad 120kg
MaxSpeed 25km/hlimited
Gradeability 15°
MaxRange 45-55 km
Frame Aluminumalloy
Tire size 8,5”
Tiretype Airtire
Brake Reardrumbrake
Netweight 17,8kg
Sizeunfolded 1120x560x1245 mm
Sizefolded 1050x180x440 mm
Voltage 48V
Batterycapacity 13Ah
Power 500 W
Chargerinput
voltage
AC110-240V
Chargerinput
current
2A
Suspension
Frontanddouble
rear
Display
Multifunctional
colorLCDdisplay
withUSBcharging
port
Charginghours 6-7h
3
4
11 12 19
1413
5
18
17
16
15
1
2
6
8
7
10
9
