Joyor F Series User Manual

02 03
ENEN
1
THE MAIN PARTS & TECHNICAL
SPECIFICATIONS
1.1 F Series: Main Parts
1. LCDdisplay
2. Lockingsleeve
3. Brakehandlewithbell
4. Brakewire
5. Leverlockforhandlebar
6. Frontsuspension
7. Frontlight
8. Frontmudguard
9. Frontairtire
10.Foldingsystem
11. Parkingstand
12. Rearmudguard
13. Rearlight
14.Reardrumbrake
15.Rearsolidtire
16.Doublerearsuspension
 (F5+andF5S+)
1.2 F Series: Technical Specifications
Model F1 F3 F5+ F5S+
MaxLoad 120kg
MaxSpeed 25km/hlimited
Gradeability 15°
MaxRange 15-20 km 30-40 km 50-60 km 40-50 km
Frame Aluminumalloy
Tire size 8”
Tiretype Airfrontandsolidrear
Brake Reardrumbrake
Netweight 12,9kg 13,5kg 16,5kg 16kg
Sizeunfolded 980x540x1140 mm
Sizefolded 880x180x360 mm
Voltage 36V 48V
Batterycapacity 7.8Ah 13Ah 18Ah 13Ah
Power 350 W 500 W
Chargerinput
voltage
AC100-240V
Chargerinput
current
2A
Suspension Front
Frontanddouble
rear
Display
MultifunctionalcolorLCDdisplaywith
USBchargingport
Charginghours 3-4h 6-7h 9-10h 6-7h
3
1
16
4
13
12
14
8
15
9 11
6
2
5
7
10
