INSTRUCTION MANUAL
10
BACKSTAY LENGTH = 930mm
MAST RAKE = 750mm
Measurement taken from back edge of rubber bumper
Measurement taken from centre of the hole in the Forestay Fitting
Measurement taken from centre of the hole in the Backstay Crane
Measurement taken from the top of the Backstay Hook
