JOYTECH PK300DC - Page 10

9
Installation direction: door opens inward (PK300DC)
Note:Note: LimitLimit stopperstopper mustmust bebe installedinstalled
L
K
L=620+5L=620+5
K＜620+340620+340
A
B
Figure 8
100 110 120 130 140 150 160 170 180 190 200
100
110
120
130
140
150
160
170
180
190
200
Max 90°
Max 100°
Max 110°
Max 120°
mmmm
B
A
Figure 9
Note: Value B must be close to or equal to the value A to obtain the best mechanical
advantage.
