JOYTECH PK300DC - Page 4

3
2. Packing List (optional)
No.
Name
Quantity
1
Infrared sensor
1
2
0
8
5 6
97
4
1 2 3
Wireless keypad
1
3
Alarm lamp
1
4
Electronic lock
1
5
Storage battery
2
3. Technical Parameters
Model
PK300DC
PK350DC
Power supply
220V/50Hz;110V/60Hz
220V/50Hz;110V/60Hz
Motor power
80W
80W
Gate moving speed
18~22 second per 90 (approx)
18~22 second per 90 (approx)
Max.single-leaf weight
300Kg
300Kg
Max.single-leaf length
2.5M
3.0M
Max.piston stroke:
34cm
54cm
Max.force
1500N
1500N
Remote control distance
≥30m
≥30m
Remote control mode
Single button mode
Single button mode
Storage battery (optional)
24V or 12 VDC
24V or 12 VDC
Noise
≤58dB
≤58dB
Working duty
S2, 30min
S2, 30min
Recording of up remote controls
25
25
Frequency
433.92 MHz
433.92 MHz
Working temperature
-20°C - +70°C
-20°C - +70°C
Package weight
17Kg
19Kg
