NXU-2A Operations Manual
1-2 Interoperability Now!
following this initial setup, a standard web browser can be used over the network to view and
change the unit’s settings and also to perform diagnostic tests.
Designed for years of continuous operation in mission-critical applications and remote
locations, the NXU-2A has no moving parts and requires no periodic shutdown or maintenance.
Start up upon power on is typically 5 seconds.
1.3 Network Details
The NXU-2A is a 10/100BASE-T Ethernet device and each unit has a unique Ethernet address
and an RJ-45 physical interface jack. A 10/100BASE-T device operates at either 10 or 100
Mbps and interconnects to an Ethernet hub or switch using standard CAT 5 twisted pair cable,
also known as UTP. The maximum cable length between an NXU-2A and its hub port is 100
meters. With the right connective equipment (recommended or supplied by JPS), the NXU-
2A’s Ethernet port can be linked with virtually any LAN, WAN, or the Internet, no matter
which topology or cabling system is in use.
