Step
#12
Sub
T
rim
In
FUNC.
L
IST
rotate
the
Selector
until
S
ub
T
r
i
m
is
highlighted.
Press
the
Selector
to
access
the
Sub
Trim
menu.
Rotate
the
Selector
to
highlight
the
desire
channel
then
press
the
Selector
to
change
the
sub
trim
value
of
the
selected
channel.
Sub
trim
all
functions
so
that
hey are in the neutral position
(see
flap
note
below).
Press
the
LIST
button
to
return
to
the
Function
Mode screen.
Note:
Typical
flap
geometry
requires
that
the
sub
trim
be
significantly
offset
to
provide
adequate
down
flap
throw.
This
issue
exists
because
flaps
typically
have
a
large
travel
down
(80
to
90
degrees)
but
very
little
travel
up
(less
than
15
degrees).
To
achieve
proper
flap
travel,
it
is
necessary
that
the
right
flap
sub
trim
be
set
at
225
down
and
the
left
flap
sub
trim
be
set
at
225
up
as
a
starting
point.
Then
when
attaching
the
flap
servo
arms
be
sure
the
spoiler
stick
is
in
the
up
position
and
camber
lever
is
in
the
middle
position.
Install
the
flap
servo
horns
such
that
they
are
angled
approximately
30%
toward
the
trailing
edge,
then
adjust
the
flap
linkage
such
that
the
flaps
are
level.
Sail
p
lane
P
r
o
g
r
ammin
g
Guide
8
