Step #31 Dual Ra
t
e and Exponential
–
Land Mode
In FUNC. L IST, rotate the Selector until D/R & EXP is
highlighted. Press the Selector to access the Dual Rate
and Exponential menu. Rotate the Selector to highlight
the channel (aile, elev or rudd) then press the Selector to
select
the desired channel that you wish to adjust the
dual and expo rates for. Rotate to select then press the
Selector to store the desired channel.
Note that three D/R and EXPO positions (values) are
available (Pos0, 1 and 2).
Under A UTO on the right of the screen, rotate the
Selector until L A ND is highlighted and press the
Selector. Select POS2 as the active position for the
land mode by rotating the Selector and then pressing
the Selector when POS2 is highlighted. This will
automatically access dual rate and expo values that are
programmed
into position 2 whenever the land mode is
selected.
Now rotate the Selector to POS2 and depress
the
Selector to highlight the D/R values. Rotating the
Selector changes these values. Displacing the aileron
stick right or left allows the dual rate to be
independently adjusted in each direction. Depress the
Selector to store the desired D/R values. Rotate the
Selector to the EXP P os 2 values and adjust these
values in the same manor, pressing the Selector to
store the desired value.
Now go back to channel and do the same thing for the
two remaining channels. Press the LIST button to return
to the Function Mode screen.
Step #32 Eleva
t
o
r
-to-Flap Mix
This function is normally not used in Land mode. It was
addressed above in setting up the Cruise mode. Step
#33
Aileron-to-Flap
This function is normally not used in Land mode.It was
addressed
above in setting up the Launch and Cruise
modes.
23 Sail
p
lane P
r
o
g
r
ammin
g
Guide
