1.3 CONFIGURATION
.
Notes:
1. The drive motor for the scanner unit is available in 220 V AC (three-phase) type and
100/110/220 V AC (single-phase) type.
2. The scanner unit can be equipped with a deicing heater as an option marked with (*), in stead of
which “-D” shall be suffixed to the type name.
3. When using the ship’s mains of 440 V AC as the radar power source, a step-down transformer
shall be used.
4. The name plates for the radar components indicate as follows:
Scanner Unit: SCANNER UNIT
Transmitter-receiver Unit: TRANSMITTER-RECEIVER UNIT
Display Unit: DISPLAY UNIT
