Day/Night
Mode Selection
IDAY/NIGHTI'
Whenever the
[DAY/NIGHT]
switch
is
pressed,
the
mode
is changed over from
IDTYI
---
F-Afa--
N|GHTn
---
lNGHTtl
and
the current
mode is indicated at the
lower right
of the
radar display.
The
brilfiance
levels selected for each mode are saved.
For
brilliance
adjustment, reter to
page
3
-12.
For selection of
DAY/NIGHT
mode by
menu operation,
refer
to
"Color
Setting" on the
next
page.
Golor
Setting
[COLOR]
The colors of
the Day/Night mode
[Day1,
2/N|GHT1, 2], system,
background color outside
the
bearing scale,
background
color
inside the bearing
scale,
echoes,
characters,
dials,
own
ship's
track,
and
radar trails are
set
up.
Color
Adjustment
by
Menu
Operalion
IDAY/NtGHTI
ISYSTEMI
louTER
PPrl
INNER
PP|l
[CHARACTER]
lDrALl
lEcHol
ITRATLSI
lowN
TRACKI
Register of
DAY/NIGHT mode
System color
adjustment
Adjustment
of the background
color outside the bearing
scale
Adjustment of the background
color inside the bearing scale
Adjustment of character colors
Adjustment
of dial
color
Adjustment
of echo
colors
Adjustment
of the
color
of
radar
trails
Adjustment
of the color of own
ship's track
[@@ll
1 Gtick the
lMENulon
the screen.
The
Main
Menu will
appear.
Click
81
MENU
The
Subl Menu will
appear.
Click
UB2
MEN
The
Sub2
Menu
will appear.
4
Click ICOLORI
The
COLOR Menu will
appear.
3-22
