43
MINIATURE MUSIC INSTRUMENT WIRELESS SYSTEM
(1) Before mount receivers onto DR-900 rack adaptor, please
release any cables from the rear of the receiver.
(2) Turn over receiver and DR-900 rack adaptor simultaneously,
there are 4 threaded holes at the bottom of receiver and
rack adaptor for inserting screws.
(3) Single receiver
Insert in a receiver through the front of DR-900 until it is
rmly attached to the rack, then screw on a RP-900 to an-
other side of the rack.
(4) Dual receivers
The same way as above, put one receiver to each rack space.
7. Rack Mounting
To Next Page
