2. Installing the legs:
a. Screw the base T-Handle clockwise into the bottom of the base
casting, until the T-Handle engages the threads (Figure 4.)
b. Slide the three legs into place. Be sure the end of each leg is
completely inserted and in contact with the back of the casting
slot.
c. Hand tighten the base T-Handle and set the “bottom” of the
machine on its legs.
d. If the legs appear wobbly:
• Make sure the legs are snug and properly placed in the base.
• Make sure the base T-Handle is turned as tightly, by hand, as
possible.
• Be sure the legs are equidistant from one other (Figure 5.)
Assembly
Figure 4 Figure 5
