18
Operation
14. To regulate the height of the pitch:
• Hold the feed chute handle and loosen the Vertical T-Handle.
• Move the feed chute TOWARDS home plate for a lower pitch
Move the feed chute AWAY from home plate for a higher pitch.
• Hand tighten the Vertical T-Handle.
15. To regulate the direction of the pitch:
• Loosen the Horizontal T-Handle.
• Grasp the chute handle and move the “top” of the JUGS sideways
until the chute is aimed at the desired target.
• Hand tighten Horizontal T-Handle.
NOTE: When throwing faster pitches (dial setting 45-70 mph), be sure to
line up Horizontal T-Handle over the red dot on the base and then
tighten the Horizontal T-Handle. To make small lateral adjustments (for
example, from “outside corner” pitches to “inside corner” pitches) simply
“shift” the legs of the pitching machine slightly by gently tapping the
legs with your foot.
WARNING:
Never loosen the Vertical T-Handle without holding the
chute handle.
