JUKI DDL-8700A-7 Cautions For Safety

vii
CAUTION BEFORE OPERATION
• Clean the sewing machine thoroughly before using it for the rst time.
• Remove all dust collected on the sewing machine during the transportation.
• Conrm that the voltage and phase are correct.
• Conrm that the power plug is properly connected.
• Never use the sewing machine in the state where the voltage type is different from the
designated one.
• The direction of rotation of the sewing machine is counterclockwise as observed from the
handwheel side. Be careful not to rotate it in reverse direction.
• Do not tilt the machine head toward this side since oil leakage or parts breakage occurs.
• A safety switch is installed so that the sewing machine cannot be operated with the machine
head tilted.
• When operating the sewing machine, turn ON the power switch after properly setting the head
on the table.
• Before starting a test run, remove the bobbin case and the needle thread from the machine.
• Operate the handwheel after the sewing machine has totally stopped.
WARNING :
To avoid malfunction and damage of the machine, conrm the following.
16. To prevent res, periodically draw out the power plug from the plug socket and
clean the root of the pins and the space between pins.
17. The hook rotates at a high speed while the machine is in operation. To prevent
possible injury to hands, be sure to keep your hands away from the vicinity of the
hook during operation. In addition, be sure to turn OFF the power to the machine
when replacing the bobbin.
18.
The motor does not produce noise while the machine is at rest. To avoid possible
accidents due to abrupt start of the machine, be sure to turn OFF the power to the
machine.
19.
When tilting or returning the sewing machine to the home position, hold the upper
side of the machine head with both hands and perform the work quietly so that
ngers or the like are not caught in the machine.
20.
Never lower the needle bar when the picker is brought close to the bobbin. The
picker may be damaged by the needle, causing a stitching failure.
21.
When the sewing machine is used for the first time after delivery or after an
extended time of disuse, remove rubber plug from the frame cover and apply a few
drops of oil to the needle bar. If the sewing machine is used with no oil added to
the needle bar, the needle bar may be seized due to abrasion of the needle bar or
intrusion of dust.
22.
This is a Class A product. In a domestic environment this product may cause radio
interference, in which case the user may be required to make corrective actions.
