− 104 −
Upload : Downloading from the smart media is read from the folder of "PROG\SC915" or "SC916".
Download : Store the copy from other media or the like in the folder of "PROG\SC915" or "SC916".
1 Create folder "PROG" in the smart media.
2 Create folder "SC915" or "SC916" in the PROG folder.
(It is not necessary to create the folder when it already exists.)
3 Copy the program file (extension PRG).
8) Program data
1. When the change of software occurs in the future due to Ver-up or the like, rewriting of the program can be
performed. Rewriting of the program is performed with each CPU.
Communication screen (Download of IP-100 program data)
Folder structure of program (* .PRG) file in the smart media
Smart media
PROG
* SC915 (Excluding LZ-2290A-SR)
* SC916 (LZ-2290A-SR only)
VDATA
IP010101.PRG
MA010101.PRG
MT010101.PRG
* SC915
* SC916
BT010101.PRG (SC916 only)
To Next Page
