– 22 –
Thread the machine head following the order as illustrated in the gure.
Pass the left-hand needle thread, toward the machine head, in the order of
❶
to
. Pass the right-hand
needle thread in the order of
A
to
P
.
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o and ascertaining that the motor is at rest.
[A type and F type]
❶
❷
A
B
❾
❽
-
I
❼ H G
E
F
❺
C
D
❸❹
J
-
K
-
L
-
M
-
N
O
P
K
❻
1. Be careful of threading of needle clamp thread guides (
,
O
).
･
See Fig. 1 for thin lament thread of yarn count #50 or higher, and Fig. 2 for thick lament
thread of yarn count #50 or lower, lament thread around yarn count #50 and polyester spun
thread.
2. Pass right-side needle thread through the upper side of thread guide pin
H
.
3. Pass the thread through the intermediate thread guide of LH-3528A-7 and 3568A-7 as follows.
･
Fig. 3 for polyester spun thread. Fig. 4 for lament thread.
Left-hand
needle thread
Right-hand
needle thread
Intermediate
thread guide
Fig. 4
Fig. 3
Fig. 1
Fig. 2
To Next Page
