− 39 −
2) Press key in the state that memory switch
No. 1 is indicated to make the sewing LED light
up. The contents of memory switch No. 1 (max.
sewing speed limitation value of the sewing
machine) are indicated.
3) Set "1800" with or key.
4) Register the value with key. Sewing LED goes off.
5) Press key to return to the normal state.
The sewing machine speed in the normal state cannot be increased more than the value
which has been set here.
(2) Setting the soft start speed at the sewing start
The speed of the first stitch to the fifth stitch at the sewing start can be set in a unit of 100 rpm. Two kinds of
settings, in case of with needle thread clamp and of without needle thread clamp can be performed. (See
Table of functions of the memory switch.)
In case of with needle thread clamp Unit : rpm
For the max. sewing speed, the memory switch No. 1 (max. sewing speed limitation) has
priority.
Setting example : In case of with needle thread clamp, the speed is changed as follows.
1st stitch from 1,500 to 1,000 rpm and 2nd stitch from 3,000 to 2,000 rpm
1) Press key in the state that the sewing LED
is put out.
2) Indicate memory switch No. 2 with or
key.
Here, set the sewing speed of the first stitch.
3) Press key. The sewing LED lights up and
the set value of the first stitch is indicated.
State when delivered Setting range
1st stitch 1500 400 to 1500
2nd stitch 3000 400 to 3000
3rd stitch 3000 400 to 3000
4th stitch 3000 400 to 3000
5th stitch 3000 400 to 3000
e
e
e
e
e
To Next Page
