2. NAME OF EACH COMPONENT
1 Needle thread draw-out device 8 Knee lifter lever !5 Tension controller No. 1
2 Wiper evice 9 Power switch !6 Thread stand
3 Thread take-up cover !0 Hand switch !7 Setting display section
4 Finger guard !1 Stitch length dial !8 Reverse feed stitching lever
5 Thread tension controller !2 Condensation dial
6 Control box !3 Control panel
7 Pedal !4 Bobbin winder
1
2
3
4
5
6
7
8
9
!0
!1
!2
!3
!4
!5
!6
!7
!8
