Soft-texture seam quality.
■ Hook-driving shaft offset
mechanism
You can quickly create an original stitching pattern on the operation
panel and then try to sew it on a trial basis.
A wider variation in design enables the machine to respond to wider
applications, such as foundations, ladies' wear and men's wear.
The machine requires neither a programming device nor ROM writer.
Abundant variation in stitching.
● Custom patterns
• Original sewing patterns can be quickly
created and stored in memory.
• Max. 20 patterns, Max. 500 stitches /pattern.
● Mirroring of scallop stitches
• The machine produces beautifully finished
scallop stitches on front part of a girdle. etc.
• For the scallop stitch, the starting position for
sewing can be selected between the top and
bottom of a scallop.
● Setting the number of stitches
for a blind stitching pattern
• The user can set the
number of stitches
for a pattern.
(3 to 250 stitches.)
● Setting of the left and right stopping positions
• The left and right
stopping positions of the
needle can be controlled.
•
These settings are
effective when
performing corner
stitching for label
attachment or decorative
stitching on the fronts of
● Continuous stitching
• Custom patterns can be
joined.
• Max. 10 patterns,
Max. 20 steps / pattern, and
Max. 500 stitches / step
● Program stitching
• As many as 20 different constant-dimension
stitch patterns can be programmed.
The maximum number of stitches that can be
set for one step is 500.
● Cycle sewing
• The machine is able to sew different patterns
while changing them in sequence.
• Max. 10 patterns, Max. 20 steps / pattern, and
Max. 500 stitches / step
● Multi-layer stitching
• It is used for reinforcing
fastening stitches or bartacks.
● Condense custom patterns ✽Automatic reverse feed function is required.
• The user can specify original condense custom patterns.
This type of pattern is very effective at producing improved
bartacks and keeping seams from being left undone.
• Start and end of sewing: A maximum of
20 different patterns, with a max. of 64
steps/pattern.
• The machine, with its automatic thread
trimmer, is able to leave shorter thread
after thread trimming as compared with
the conventional machines.
(Example)
(Example)
Bartacks
(Example)
Stop the sewing machine
and press mirror
inversion switch.
Mirror inversion
operation LED
lights up.
Afterwards
inversion
operation
The position at which the
blade point of the hook
tacks the thread is almost
uniform.
Scallop: 1 pattern
Stitching direction
Mirror inversion switch
(Example)
(Example)
Blind stitch: 1
pattern
6 stitches
10 stitches
(Example)
(Example)
Start point
Step 1
Step 2
Step 3
Step 4
Pattern combining
patterns A, C, B and C
A
C
B
C
Custom patterns can be created
on the operation panel with ease.
Keeping seams from
being left undone
Shorter length of
thread remaining
after thread trimming
Left stopping position
of the needle
Right stopping position
of the needle
Stitching
direction
Stitching
direction
Left Right
✱
✱
✱
✱
✱
The thread tension mechanism, bobbin
case and feed timing have been improved
to produce soft-textured seams.
The machine is equipped with a hook-
driving shaft-offset mechanism which
places the hook-rotating shaft off-center
from the center of zigzag stroke of the
needle. This mechanism allows the blade
point of the hook to catch the needle
thread every time regardless of the needle
throwing direction. As a result, the
machine is immune to sewing troubles
such as stitch skipping and thread
breakage, annoyances likely to occur with
the conventional machine, especially
when the needle throws to the right.
For the minute-quantity lubrication type hook,
the inner hook is finished with titanium to keep it
from becoming hot. The machine requires only a
very small quantity of oil. This prevents oil stains
on the material and the improves durability of the
hook. In addition, the hook configuration is
carefully designed to avoid needle breakage.
!
