LZ-2290A Series User Manual

■ Specifications
KI distributor.
Code
en) AK121
Machine head type Dry-head type Minute-quantity lubrication type
Model name
Without automatic
thread trimmer
LZ-2290A-DS LZ-2290A-DU LZ-2290A-SS LZ-2290A-SU
With automatic
thread trimmer
LZ-2290A-DS-7 LZ-2290A-DU-7 LZ-2290A-SS-7 LZ-2290A-SU-7
Type Standard
Anti-material-slip
Standard
Anti-material-slip
capability type capability type
Max. sewing speed
4,000sti/min
※
5,000sti/min
※
4,500sti/min
※
(for standard zigzag stitching, the zigzag width (for standard zigzag stitching, the zigzag width
has to be set to 5mm or less.) has to be set to 4mm or less.)
Max. zigzag width 10min(inincrementsof0.1min)
Needle throw mechanism Computer-controlled
Max. Stitch length
5.0mm 2.5mm 5.0mm 2.5mm
Stepless fine adjustment
Lift of the presser foot By hand: 5.5mm/ By knee: 10mm
Hook
Exclusive no-lubricating hook
(plastic hook with special-purpose race surface)
DP hook (with titanium-treated inner hook)
Thread take-up Rotary type
Needle (at the time of delivery) 438(Nm75), DP
×5(#10)
Number of patterns for standard stitching 8 types/ 14 patterns
Internal memory Max. 20 patterns
Extended memory Max. 999 patterns
Max. number of stitches 500 stitches/ pattern
Continuous stitching pattern Max. 10 patterns, 20 step, 500 stitches/step
Input function of the main unit Provided as standard (operation panel: IT-100D)
Bobbin thread winder Built-in machine head
Machine head drive Compact AC servomotor (direct-drive system)
Lubrication No lubrication
Minute-quantity lubrication to needlebar and
hook (no oil pan system)
Lubricating oil ––
JUKI New Defrix Oil No.1
(equivalent to ISO VG7)
Distance from needle to machine arm 300mm
Bed size 517mm
×178mm
Power requirement/
Power consumption
Single-phase 100~120V, 200~240V, 3-phase 200~240V/Power rating 600VA
Total weight
98kg (without automatic thread trimmer)
100kg (with automatic thread trimmer)
Custom pattern
memory capacity
✽ “sti/min” stands for “Stitches per minute”
