01
The machine is provided with many different stitching patterns.
Advanced operation panel
IT-100
The next-generation standard zigzag stitching machine LZ-2290A Series
–––––––––––––––––––––––
Example of screen displays
–––––––––––––––––––––––––
It comes in two different models, one with standard specifications
and the other with an anti-material slip capability. For both
models, there are two subclass models, i.e., the "minute-quantity
lubrication type" and the "dry-head type", which eliminates oil
stains on sewing products. You may select the best-suited model
from the diversified subclasses according to your applications.
The machine is also provided with a newly-developed operation
panel, the IT-100. With this operation panel, you can easily
establish settings for stitch shapes and stitches, as well as conduct
setup changing, thereby achieving further increased availability.
A liquid crystal display has been
adopted. It displays stitch shapes,
zigzag width and standard lines with
pictographs and settings all together
on one screen to improve operability
of the panel.
The machine has added capabilities
that make the most out of the
computer-controlled sewing machine
functions, such as program stitching
(constant-dimension sewing), cycle
sewing and continuous sewing.
With these capabilities, the machine is
able to respond to sewing in various
processes.
Custom pattern data can be stored
using the same USB memory.This
enables the sharing of custom
patterns, not only in one plant, but
also among two or more sewing
plants, by exchanging data via e-mail
systems.
The machine is provided as standard with fourteen different
basic zigzag stitching patterns grouped into eight different
types. You can choose the zigzag stitching pattern you want
directly on the operation panel (IT-100) of the machine body.
The zigzag width, needle throw position and number of blind
stitches can also be easily adjusted on the operation panel.
A single unit is extremely versatile and can perform straight
stitching, standard zigzag stitching, 2-step zigzag stitching,
3-step zigzag stitching, scallop stitching, and blind stitching.
As a result, the system is available for a far wider range of
applications.
Scallop stitch shape setting
Continuous stitching
Maintenance function
■ Sewing pattern
Name of
pattern
Stitch
pattern
Number of
stitches
1246 24
Straight
stitch
Standard
zigzag
2-step
zigzag
3-step
zigzag
Standard Crescent
Equal-
width
Equal-
width
Standard Crescent
Equal-
width
Equal-
width
Scallop (left) Scallop (right) Blind
stitch
(left)
Blind
stitch
(right)
Custom
pattern
12 24 12 3~250
Max. 500
✱
✱
✱
✱
✱
A single LZ-2290A Series machine is extremely versatile and
can perform many different stitching patterns.
