24
–
2
5
3
1
7
6
The tension release com-
ponents can be removed
as an entire unit by remov-
ing the following setscrews:
・
Four setscrews
2
of ten-
sion release solenoid
1
.
・
Two setscrews
3
of sole-
noid stopper asm.
・
Two setscrews
2
of the
tension release link.
・
One hinge screw
5
.
Adjust so that tension disc
6
floats by 1 mm when
tension release solenoid
1
is pulled. Then, fix tension
release solenoid
1
with four
setscrews
2
.
Adjust solenoid stopper
(asm.)
7
so that a clearance
of 4 mm is provided between
the tip of the stopper and
the solenoid link when pull-
ing the magnet. Then, fix it
with two setscrews
3
of the
stopper mounting plate.
Smooth operation of the
tension release link has
to be ensured.
Tension disc
6
should
not float when tension
release solenoid
1
is
in its standby position
(the power is in the OFF
state).
Hexagonal wrench
key (3 mm)
Flatblade screwdriver
WARNING :
3
（
）
