Julabo F25-HE - 9.6. MENU SERIAL - Communication

Menu functions
58
9.6. MENU SERIAL - BAUDRATE, HANDSHAKE, PARITY
Menu level 1
Ð
For communication between circulator and a PC or a superordinated process
control system the interface parameters of both units must be identical.
L For remote control refer to page 81
Factory settings:
4800 Baud
even
hardware handshake
Level 2 Parameter level
L Press the key if a parameter is to be
retained.
Î
x The parameter flashes, switch by pressing
and
Î
x The parameter flashes, switch by pressing
and
even: Data bits = 7; Stop bits = 1
odd: Data bits = 7; Stop bits = 1
no: Data bits = 8; Stop bits = 1
Î
x The parameter flashes, switch by pressing
and
Xon/Xoff-protocol (Software handshake)
Protocol RTS/CTS (Hardware handshake)
