Command Parameter Response of circulator
OUT_MODE_03
0 Set external programmer input to voltage.
Voltage 0 V ... 10 V
OUT_MODE_03
1 Set external programmer input to current.
Current 0 mA ... 20 mA
OUT_MODE_04
0 Temperature control of internal bath.
OUT_MODE_04
1
External control with Pt100 sensor.
OUT_MODE_05
0 Stop the unit = R –OFF-.
OUT_MODE_05
1 Start the unit.
OUT_MODE_08
0 Set the control dynamics - aperiodic
OUT_MODE_08
1
Set the control dynamics - standard
OUT_SP_00
xxx.xx Set working temperature. “Setpoint 1”
OUT_SP_01
xxx.xx Set working temperature. “Setpoint 2”
OUT_SP_02
xxx.xx
Set working temperature. “Setpoint 3”
OUT_SP_03
xxx.xx Set high temperature warning limit “OverTemp”
OUT_SP_04
xxx.xx Set low temperature warning limit “SubTemp”
OUT_SP_06
xxx.xx Set manipulated variable for heater via serial interface
-100 ... +100 [%]
OUT_SP_07
x Set the pump pressure stage. (1 ... 4)
OUT_PAR_04
x.x CoSpeed for external control 0 ... 5.0.
OUT_PAR_06
xxx
Xp control parameter of the internal controller. 0.1 ... 99.9
OUT_PAR_07
xxx Tn control parameter of the internal controller. 3 ... 9999
OUT_PAR_08
xxx Tv control parameter of the internal controller. 0 ... 999
OUT_PAR_09
xxx Xp control parameter of the cascade controller. 0.1 ... 99.9
OUT_PAR_10
xxx Proportional share of the cascade controller. 1 ... 99.9
OUT_PAR_11
xxx
Tn control parameter of the cascade controller. 3 ... 9999
OUT_PAR_12
xxx Tv control parameter of the cascade controller. 0 ... 999
OUT_PAR_13
xxx Maximum internal temperature of the cascade controller.
OUT_PAR_14
xxx
Minimum internal temperature of the cascade controller.
OUT_PAR_15
xxx
Band limit (upper) 0 ... 200 °C
OUT_PAR_16
xxx Band limit (lower) 0 ... 200 °C
OUT_HIL_00
-xxx Set the desired maximum cooling power (0% to 100%).
Note: Enter the value with a preceding negative sign!
This setting is meaningful only for FP cooling machines.
OUT_HIL_01
xxx Set the desired maximum heating power (10% to 100%).
