Remote control
86
IN commands: Asking for parameters or temperature values to be displayed.
Command Parameter Response of circulator
VERSION
None Version number of the software (V X.xx)
STATUS
none Status message, error message (see page 88)
IN_PV_00
none Current bath temperature.
IN_PV_01
none Heating power being used (%).
IN_PV_02
none Temperature value registered by the external Pt100 sensor.
IN_PV_03
none Temperature value registered by the safety sensor.
IN_PV_04
none Setpoint temperature (“SafeTemp”) of the excess
temperature protection
IN_SP_00
none Working temperature “Setpoint 1”
IN_SP_01
none Working temperature “Setpoint 2”
IN_SP_02
none Working temperature “Setpoint 3”
IN_SP_03
none High temperature warning limit “OverTemp”
IN_SP_04
none Low temperature warning limit “SubTemp”
IN_SP_05
none Setpoint temperature of the external programmer
(REG+E-PROG).
IN_SP_06
none Temperature indication in °C or °F
IN_SP_07
none 1. Adjusted pump stage in the -OFF- condition.
2. Pump stage corresponding to the effective rotational
speed after start.
IN_SP_08
none Value of a flow rate sensor connected to the E-Prog input
IN_SP_09
none Value of a pressure sensor connected to the E-Prog input
IN_PAR_00
none Temperature difference between working sensor and safety
sensor
IN_PAR_01
none Te - Time constant of the external bath.
IN_PAR_02
none Si - Internal slope
IN_PAR_03
none Ti - Time constant of the internal bath.
IN_PAR_04
none CoSpeed - Band limit (max. difference between the
temperatures in the internal bath and external system).
IN_PAR_05
none Factor pk/ph0:
Ratio of max. cooling capacity to max. heating capacity
IN_PAR_06
none Xp control parameter of the internal controller.
IN_PAR_07
none Tn control parameter of the internal controller.
