Julabo FP51-SL - Technical Specifications

FP51-SL
9
2.2. Technical specifications
Ultra-Low Refrigerated Circulator
FP51-SL
Working temperature range
°C
-51 ... 200
Temperature stability
°C
±0,05
Cooling capacity
°C
+20 0 -20 -40
Medium: ethanol
kW
2.0 1.5 1.0 0.26
Cooling compressor
1-stage
Refrigerant
R507
Overall dimensions (WxDxH)
cm
46x55x89
Bath opening (WxL)
cm
18x12
Bath depth
cm
20
Filling volume
liters
7,5 ... 12
Weight
kg
90
Ambient temperature
°C
5 ... 40
Mains power connection z
V/ Hz
400 ±10 % / 50 / 3PNPE
Current draw (at 400 V)
A
16
Mains power connection V/ Hz 208 -5%; +10% − 230 ±10 % / 60 / 3PPE
Current draw (at 230 V)
A
16
Mains power connection
V/ Hz
230 ±10 % / 50 / 3PPE
Current draw (at 230 V)
A
16
SL
Temperature selection
digital
via keypad
indication on LCD DIALOG-DISPLAY (°C/°F)
remote control via PC
indication on monitor
Temperature indication
VFD COMFORT-DISPLAY (°C/°F)
Resolution
°C
0.01
ATC3 INT / EXT
°C
±3 / ±9
Temperature control
ICC - Intelligent Cascade Control
Heater wattage (at 230 V)
kW
3.0
Electronically adj. pump capacity
stages
1 ... 4
Flow rate at 0 bar
l/min
22 ... 26
Max. pressure at 0 liters
bar
0.7
Max. suction at 0 liters
bar
0.4
Electrical connections: see page 10
Ambient temperature
°C
5 ... 40
Mains power connection
V/ Hz
208 ±10 % / 230 ±10 % / 50 / 60
Current draw (at 208 V / 230 V)
A
13 / 14
All measurements have been carried out at: rated voltage and frequency
ambient temperature: 20 °C Technical changes without prior notification reserved.
