JUMO EM Series Operating Instructions

3 Installation
12
3.3.2 Approved process connections
Temperature
probe
10
Screw-
connections
50, 52, 54, 60, 65
Sheaths 20, 21, 22, 23, 24, 40, 41, 42
3.3.3 Sheath made of steel 22, 23, 32, 41, 42 and 45
Material
Capacity
max. admissible
operating
temperature
H
refer to data sheet 606710 !
Tube Screw-in nipples Welding nipples
St 35.8 I Steel 1.0038 Steel 1.5415
Temperature Pipe diameter
8 x 0.75 mm or
conical
10 x 0.75 mm 15 x 0.75 mm
Maximum admissible pressure
100 °C 89 bar 72 bar 48 bar
150 °C 83 bar 67 bar 45 bar
200 °C 78 bar 63 bar 42 bar
300 °C 59 bar 47 bar 32 bar
350 °C 50 bar 40 bar 27 bar
Tube Nipple max. admissible operating temperature*
static load without load
St 35.8 I Screw-in nipples +300 °C
+530 °C
Welding nipples +450 °C
* observe the max. admissible probe temperature of the respective thermostat version.
For operating temperatures > +420 °C: observe the operating life of 200,000 h at a static
load TRD508. Sheath "21" (UO) and "31" (UZO): Use only in pressureless medium.

JUMO EM Series Specifications

General

Housing Material	Plastic
Temperature Range	-50 to 400°C
Display	LCD
Power Supply	24 V AC/DC
Output	Relay, Analog
Input	Analog
Control Mode	PID, On/Off
