JUMO EM Series Operating Instructions

3 Installation
14
3.3.4 Sheath made of stainless steel 20, 22, 40 and 41
Capacity
3.3.5 Sheath made of brass 20 and 40
Capacity
3.3.6 Probe connections 50, 52 and 54
(probe making directly contact with the medium)
Material of pipe and nipple: Stainless steel (1.4571)
Temperature
Pipe diameter Ø
8 x 0.75 mm
or conical
10 x 0.75 mm 15 x 0.75 mm
Maximum admissible pressure
100°C 92bar 74bar 50bar
150°C 88bar 71bar 48bar
200°C 83bar 67bar 45bar
300°C 72bar 58bar 39bar
400°C 67bar 54bar 36bar
Material of pipe and nipple: CuZn, nickel plated
Temperature
Pipe diameter Ø
8 x 0.75 mm 10 x 0.75 mm 15 x 0.75 mm
Maximum admissible pressure
100°C 50bar 40bar 27bar
150°C 48bar 39bar 26bar
Material of nipple CuZn Steel (1.0038) Stainless steel (1.4571)
Temperature °C 200 300 400
Probe material Ø
mm
Device function
STB, STW (STB)
Cu-DHP
St35 1.4571
4
2 bar
5
6
7
8
9
10

JUMO EM Series Specifications

General

Housing Material	Plastic
Temperature Range	-50 to 400°C
Display	LCD
Power Supply	24 V AC/DC
Output	Relay, Analog
Input	Analog
Control Mode	PID, On/Off
