JUMO LOGOSCREEN Series - Wiring Connection Diagram

17
4 Electrical connection
4.3 Connection diagram
Back panel Rear view with pluggable screw terminals
Cover for
back panel
V
The electrical connection must only be carried out
by qualified personnel.
(L-)
(L+)
Hole for lead sealing
Holes provided for the
cable-ties supplied,
for strain relief of the
connection cables
