20
6190755 (Rev A) 86/87R Compressor System User Guide
© 2015, JUN-AIR
We reserve the right to make any alterations which may be due to any technical improvements
Printed in the USA
Part no. Description
3050005 TANK - 4L CE/UL w/inspection
3051000 4L TANK CE
3210005 TANK - 15B CE
3210098 Tank – 15B CE/ASME 16 Bar
3410010 TANK - 25B CE
3411399 TANK - 25B ASME
4071039 Filter regulator 5u w/automati
4141800 RAPID FITTING ELBOW 1/8"XO6
4146457 RAPID FITTING 06-06MM PIPE
5031000 Pressure switch MDR 2/11
5075000 Pressure switch MDR 21/11 UL
5130000 GAUGE +40 - 0-16BAR 1/8"DOWN
5237700 CAPACITOR 30UF/370V AC
5320226 Handle 86/87R-4B
5340000 Handle 87R-25/15B
5414500 Non return valve f/lubicated
5416100 SAFETY VALVE 12 BAR 177 PSI
5417000 SAFETY VALVE 9 BAR/135 PSI
5418000 DRAIN COCK 1/4" 4L
5419500 DRAIN COCK 1/4" 15L
5420000 DRAIN COCK 1/4" 25L
5424000 OUTLET COCK 1/4"
5427001 Nipple for connecting Fil/reg
5427002 Nipple for connecting Fil/reg
5427003 Connector for Fil/reg
5935011 Squeeze Box 86R single
5935012 Squeeze Box 87R Dual
5960000 CABLE RELIEF
6243710 O-RING F/OF PLUG
6243715 O-ring O7x1, 5 Viton (for 1 /
6250000 SOCKET 25 MM BLACK
6253704 Rubber Base f/82R
6290200 PLASTIC HANDLE BLACK 025MM
6293100 NUT PG16 BRASS
6294600 PG-NIPPLE M16 UL/CSA
6296850 CABLE RELEIF HEYCO 1327 ELBOW
6296851 Cable relief Heyco 1226 OF300
*6314000 M6x10 HHCS ZINC PLATE
*6320200 COUNTER NUT M8 FLAT FZB
6340500 1/8 PIPE PLUG x 7mm LONG
*6341040 M4x25 SHCS ZINC PLATE
Part no. Description
*6341101 SCREW F/UNLOADER VALVE M5X6
*6341800 M6x10 SHCS
*6346300 M8x20 FLAT HEAD ZINC PLATE
*6355000 WASHER 6.5X13X1.25MM
*6357100 Washer O18xO6.4x1.6 FZB
*6372500 LOCK NUT M4
*6372700 LOCK NUT M8 FZB
*6390000 STAR WASHER TYPE A M6
*6390025 Star washer type A M8
*6391800 SCREW PH FZB 4X12
*6391900 M2.2x12 PAN HD SHEET MTL ZINC
*6392145 SCREW GROUND
*6392202 M6 x 12MM FLAT HEAD ZINC
*6392350 M8x25 FLAT HEAD ZINC
6420000 FLEX PIPE 1/8" 20 (22)
6457020 Teflon hose 1/4" 20 cm with el
6457024 Teflon hose 1/4" 24 cm with el
6457028 Teflon hose 1/4" 28 cm with el
**6973090 Unloader valve
**6973105 Needle f/unloader valve 16.4 m
**6975002 Silencer f/unload valve OF300
7020002 Double nipple 1/8" w/o-ring
7024002 Double nipple 1/4 in w/o-ring
7025000 DOUBLE NIPPLE 1/4"X1/8"
7025005 Double nipple 1/4"x1/8" w/o-ri
7070000 CONN. PIECE F/NON-RETURN VALVE
7071000 T-PIECE 1/8"
7071350 Tee-connector 1/4" (2xexternal
7156000 EXTENSION PIECE F/COCK SHORT
7156100 EXTENSION PIECE F/COCK LONG
7164200 CROSS CONNECTOR
7180000 ELBOW 1/4" INT/EXT KRG
7190000 ELBOW 1/8"
7540000 BUSH F/5960000
7555000 Coupling nut 1/8"
7565000 BUSHING 1/4"EXT X 1/8"INT
7566200 BUSHING 1/4"X1/4" L = 35 MM
8008302 BRACKET
8111962 MOUNTING BRACKET F/ 87R-25B
B300A FILTER PLASTIC 1/4 NPT
* Not available for resale
** Only available in service kit
