6190755 (Rev A) 86/87R Compressor System User Guide
© 2015, JUN-AIR
We reserve the right to make any alterations which may be due to any technical improvements
Printed in the USA
Information
Please note that you can find the pictures and figures we
are referring to in the back of the manual
Important - read this first!
Please read the following information and operating instructions included with this product
before use. This information is for your safety and it is important that you follow these
instructions. It will also help prevent damage to the product. Failure to operate the unit in
accordance with the instructions or using JUN-AIR unauthorized spare parts can cause
damage to the unit and could cause serious injury.
CAUTION: To reduce risk of electric shock
• Only authorized service agents should carry out service. Removing parts or
attempting repairs can create an electric shock. Refer all servicing to qualified service
agents.
• If this unit is supplied with a three-pin plug, connect with a properly earthed outlet
only.
WARNING: To reduce risk of electrocution
• Do not use this unit with electrical voltages other than stated on the rating plate.
• Never leave this product unattended when plugged in.
• Always unplug this unit immediately after use.
• Store in a dry place.
• Do not use this product in or near liquid or where it can fall or be pulled into water or
other liquids.
• Do not reach for this product if it has fallen into liquid. Unplug immediately.
• This unit is not weatherproof. Never operate outdoors in the rain or in a wet area.
DANGER: To reduce risk of explosion or fire
• During spraying with combustible liquids risk of explosion may arise, particularly in
closed rooms
• Do not use this product in or near explosive atmospheres or where aerosol products
are being used.
• Do not pump any other gases other than atmospheric air.
• Do not pump combustible liquids or vapours with this product; do not use it in or
near areas with combustible or explosive liquids or vapours.
• Do not use this unit near naked flames.
CAUTION: To prevent injury
• Compressed air can be dangerous; do not direct airflow at a persons head or body.
• Always keep the system out of reach of children.
• Never operate this product if it has a damaged power lead or plug, if it has been
dropped or damaged, or if it has fallen into water. Return the product to a service
centre for examination and repair.
• Keep the electrical cable away from hot surfaces.
• Ensure all openings are kept free of restriction and never place the system on a soft
surface where the openings may be blocked. Keep all openings free from dust, dirt
and other particles.
• Never insert fingers or any other objects into fans.
• This unit is thermally protected and can automatically restart when the overload
resets.
• Wear safety glasses, when servicing this product.
• Use only in well ventilated areas.
• This product may only be connected to units or tools with a max. pressure higher or
equal to that of the system.
• The surface of the system can get hot. Do not touch system system during
operation.
Operating manual
Failure to observe the above safety precautions could result in severe bodily injury,
including death in extreme cases.
IMPORTANT: General directions for use
• Protect the system against rain, moisture, frost and dust.
• The system is constructed and approved for a max. pressure as stated under
Technical Specifications.
• Do not operate system at ambient temperatures exceeding 40°C/104°F or falling
below 5°C/41°F.
• If the supply lead on the system is defective, an authorized JUN-AIR distributor or
other qualified personnel must carry out the repair.
Warranty
Provided that the operational instructions, maintenance, and service have been carried
out, your JUN-AIR system is guaranteed against faulty material or workmanship for 2
years.
The air receiver is guaranteed for 5 years.
The guarantee does not cover damage caused by violence, misuse, incorrect repairs or
use of unoriginal spare parts.
Costs of transportation of parts/equipment are not covered by the guarantee.
JUN-AIR’s Conditions for Sale and Delivery will generally apply.
Gast Manufacturing, Inc. A/S reserves the right to change technical specifications/
constructions.
Contents of box
Your system should be delivered in a clean and undamaged box. If not, contact
your distributor immediately. The box should contain the following:
• 1 86/87R-XB system
• 1 system operating manual & 1 filter/regulator manual
• Individually packaged or attached filter/regulator
• 100 cm x 6 mm tube for filter/regulator autodrain line
Installation
Your JUN-AIR system is very easy to operate. Observe the following simple
instructions and you will get many years’ service from your unit.
• Visually inspect unit for shipping damage, contact your supplier
immediately if you think the unit may have been damaged.
Warning!
To avoid the risk of electric shock, do not install the system in
areas where it may get in contact with water or other liquids. In
which case protection is required.
• Use only pressure pipes tolerating a constant temperature of min. 150
0
C.
Ensure that the pressure pipes have a sufficient internal diameter to avoid
pressure loss in the system. Check for leaks.
GOOD BAD
Min. 5°C/41°F • Max. 40°C/104°F
