Specifications
87R-25B 87R-15B
120 V 230 V 230 V 120 V 230 V 230 V
Frequency HZ 60 50 60 60 50 60
Displacement @ 0 Bar
l/min 91 82 91 91 82 91
CFM 3,2 2,9 3,2 3,2 2,9 3,2
FAD @ 8 bar
l/min 34 28 34 34 28 34
CFM 1,2 1 1,2 1,2 1 1,2
Max Current A 5,7 2,5 2,8 5,7 2,5 2,8
Weight
kg 32 27 32 29 22 29
lbs 70 59 70 61 48,5 61
Pumping Time
0-8 bar/0-120psi
sec 185 205 185 115 125 115
Noise level
dB(a)/1m
63 61 63 63 61 63
Dimensions (LxWxH)
mm
388 x 380 x 619
388 x 380 x 548
in
15,3 x 15,0 x 24,4
15,3 x 15,0 x 21,6
Motor
HP 1/2 1/2
KW 0,37 0,37
Max Pressure
bar 8 8
psi 120 120
Tank Size
liters 25 15
gallons 6,6 4
Thermal Protection Yes Yes
Duty Cycle 100% 100%
Relative Humidity % 20 - 80%* 20 - 80%*
Ambient Temperature 5/40°C 5/40°C
* Non-Condensing
The figures in the tables are based on the unit working in a clean environment at an ambient
temperature of 20°C, relative humidity of 50% and operating at sea level. The performance of the
product will be adversely effected at high altitudes. JUN-AIR reserves the right to make technical
modifications to these units as needed.
