Jun-Air 86 - Technical Specifications; 87 R-4 B & 86 R-4 B Data

22
6190755 (Rev A) 86/87R Compressor System User Guide
© 2015, JUN-AIR
We reserve the right to make any alterations which may be due to any technical improvements
Printed in the USA
Specifica-
tions
87R-4B 86R-4B
120 V 230 V 230 V 120 V 230 V 230 V
Frequency HZ 60 50 60 60 50 60
Displacement @
0 Bar
l/min 91 82 91 40 34 40
CFM 3,2 2,9 3,2 1,41 1,20 1,41
FAD @ 8 bar
l/min 34 28 34 15,0 12,5 15,0
CFM 1,2 1 1,2 0,53 0,44 0,53
Max Current A 5,7 2,5 2,8 2,1 1,7 1,1
Weight
kg 18 18 18 15,6 15,6 15,6
lbs 40 40 40 34,4 34,4 34,4
Pumping Time
0-8 bar/0-120psi
sec 32 37 32 80 90 80
Noise level
dB(a)/1m
63 61 63 58 55 58
Dimensions
(LxWxH)
mm
404 x 306 x 338
404 x 306 x 338
in
15,9 x 12,0 x13,3
15,9 x 12,0 x13,3
Motor
HP 1/2 1/3
KW 0,37 0,25
Max Pressure
bar 8 8
psi 120 120
Tank Size
liters 4 4
gallons 1,1 1,1
Thermal Protection Yes Yes
Duty Cycle 100% 100%
Relative Humidity % 20 - 80%* 20 - 80%*
Ambient Temperature 5/40°C 5/40°C
* Non-Condensing
The figures in the tables are based on the unit working in a clean environment at an ambient
temperature of 20°C, relative humidity of 50% and operating at sea level. The performance of the
product will be adversely effected at high altitudes. JUN-AIR reserves the right to make technical
modifications to these units as needed.
