Jun-Air 86 - Model Identification; Compressor Model Coding System

25
86/87R Compressor System User Guide 6190755 (Rev A)
© 2015, JUN-AIR
We reserve the right to make any alterations which may be due to any technical improvements
Printed in the USA
Tank
Regulatory
Elec/region config
Accessory configuration
Compressor Configuration
Dryer Type
Enclosure Style
Receiver Size
Family & cylinders
87R - 25 B Q2 - X XX X X X
Compressor Accessory Elec/region config Regulatory Tank
A Single Cylinder, Low Stroke Manual tank drain, 5µ F/R manual drain,
no bottle, pressure switch unloader
100/50 or 60 Japan
(NEMA 1-15 or 5-15)
CE CE
B Single Cylinder, High Stroke (0.35") Manual tank drain, 5µ F/R auto drain,
with bottle
120/50 or 60 NA (NEMA 5-15) CSA ASME
C Single Cylinder, High Stroke (0.42") Bent
Valve (100psi max)
Manual tank drain, 5µ F/R manual drain,
0.01µ Coalescing Filter, no bottle
220-240 50 or 60 NA (NEMA 6-15) cULus ASME
Singapore
D Manual tank drain, 5µ F/R auto drain,
0.01µ Coalescing Filter, with bottle
220-240 50 or 60 EU (CEE 7/7) CE/cULus GB (china)
E Manual tank drain, 5µ F/R auto drain, no
bottle, pressure switch unloader
220-240 50 or 60 EU (CEE 7/7) &
GB adaptor
CCC CRN
F Manual tank drain, 5µ F/R auto drain,
0.01µ Coalescing Filter, no bottle
220-240 50 or 60 CH (NEMA 1-15
or AS-3112)
cCSAus ASME/CE
G Dual Parallel Cylinder, Low Stroke 220-240 50 or 60 AU (AS-3112) ASME/CRN
H Dual Parallel Cylinder, High Stroke
(0.37")
220-240 50 or 60 GB (IEC Type G) CE/UL
J Dual Parallel Cylinder, High Stroke
(0.42") Bent Valves
K Auto tank drain, 5µ F/R auto drain, with
bottle
L Auto tank drain, 5µ F/R auto drain,
0.01µ Coalescing filter, with bottle
M Auto tank drain, 5µ Filter auto drain,
regulator, solenoid unloader, no bottle
N Dual Staged Cylinders, Std Stroke Auto tank drain, 5µ Filter auto drain,
regulator, solenoid unloader, with bottle
None
P Dual Independent Cylinders, Std Stroke
R
S Special compressor configuration OEM Specific Model Special voltage/plug Special Special
Family & cylinders Receiver Size Enclosure Style Dryer Type
86R = single cylinder & small bore (low flow) 4, 15, 25, 40 B = Basic or Open Q = iQ dryer (2, 3, or 6 size)
87R = twin cylinder & large bore (high flow) M = Metal Cabinet A = Membrane Dryer
P = Plastic Cover
