2 Technical Specifications
All technical specifications refer to a standard module.
Z Technical modifications and additions reserved.
2.1 Module
Power supply
12 VDC to 48 VDC
Current consumption during operation
(maximum)
12 V - 120 mA
24 V - 60 mA
48 V - 35 mA
Standby current consumption
8 mA at 24 V
Dimensions
67.4 x 67.4 x 54.9 mm
Protection rating
IP 65 at the front
IP 54 at the back with connector plugged
in
Ambient temperature
-28°C to 65°C
Storage temperature
-40°C to 80°C
Relative air humidity
5 to 95% (in operation), no thawing
Rated RF output power
Frequency: 13,56 Mhz
Electric field intensity: < 29,5 dBµV/m
@30m
2.2 Connection Assignment for 14-Pin Connector
PIN
Signal
1
+ relay
2
Relay output
3
+ relay
4
Relay output
5
+ relay
6
Relay output
7
CANL
