0602.GB
E 14
Switching matrix / safety switching height
ERC / ERC-Z 12
ERC / ERC-Z 14/16
*
)
Sh = Safety switching height approx.1,800 mm (depending on lifting mast version)
**
)
optionally travelling (4.3 km/h) and lifting with the safety frames folded out
above 1,800 mm in conjunction with a load guard is possible.
Platform Lifting
height
Speed (km/h)
with load
Collision guard button
active
Lifting
functions
active
Folded up <Sh *
)
4.3 Yes Yes
Folded up >Sh *
)
4.3 Yes Yes
Folded out <Sh *
)
6.0 No Yes
Folded out >Sh *
)
4.3 No Yes
Platform Safety
frame
Lifting
height
Speed (km/h)
with load
Collision guard button
active
Lifting
functions
active
Folded
up
Folded
in
<Sh *
)
4.3 Yes Yes
Folded
up
Folded
in
>Sh *
)
4.3 Yes Yes
Folded
up
Folded
out
<Sh *
)
0NoNo
Folded
up
Folded
out
>Sh *
)
0NoNo
Folded
out
Folded
in
<Sh *
)
6,0 No Yes
Folded
out
Folded
in
>Sh *
)
4,3 No Yes
Folded
out
Folded
out
<Sh *
)
7.5 / 7.0 No Yes
Folded
out
Folded
out
>Sh *
)
0 **
)
No No **
)
0602.GB
E 14
Switching matrix / safety switching height
ERC / ERC-Z 12
ERC / ERC-Z 14/16
*
)
Sh = Safety switching height approx.1,800 mm (depending on lifting mast version)
**
)
optionally travelling (4.3 km/h) and lifting with the safety frames folded out
above 1,800 mm in conjunction with a load guard is possible.
Platform Lifting
height
Speed (km/h)
with load
Collision guard button
active
Lifting
functions
active
Folded up <Sh *
)
4.3 Yes Yes
Folded up >Sh *
)
4.3 Yes Yes
Folded out <Sh *
)
6.0 No Yes
Folded out >Sh *
)
4.3 No Yes
Platform Safety
frame
Lifting
height
Speed (km/h)
with load
Collision guard button
active
Lifting
functions
active
Folded
up
Folded
in
<Sh *
)
4.3 Yes Yes
Folded
up
Folded
in
>Sh *
)
4.3 Yes Yes
Folded
up
Folded
out
<Sh *
)
0NoNo
Folded
up
Folded
out
>Sh *
)
0NoNo
Folded
out
Folded
in
<Sh *
)
6,0 No Yes
Folded
out
Folded
in
>Sh *
)
4,3 No Yes
Folded
out
Folded
out
<Sh *
)
7.5 / 7.0 No Yes
Folded
out
Folded
out
>Sh *
)
0 **
)
No No **
)
