11.14 EN
20
DFG S80-S90
1)
for vertical mast.
2)
The values shown represent the maximum gradeability to overcome short
differences in height and surface unevenness (surface edges). The truck must not
operate on inclines of more than 15%.
Component S80 S90
Q Capacity
1)
8000 9000 kg
C Load centre distance 900 900 mm
Travel speed *
with / without load
22.3/22.6 22.3/22.6 km/h
Lift speed
with / without load
0.40/0.60 0.40/0.60 m/s
Lowering speed
with / without load
0.60/0.36 0.60/0.36 m/s
Gradeability
2
with / without load
21.5/25.0 20.9/24.0 %
Tow force with / without load 49.5/49.5 52.9/52.9 kN
Acceleration time *
with / without load to 15 m
7.0/6.0 7.0/6.0 sec
Available working pressure
for attachments
160 160 bar
Oil flow for attachments 80 80 l/min
