21
11.14 EN
TFG 660-690
1)
for vertical mast.
2)
The values shown represent the maximum gradeability to overcome short
differences in height and surface unevenness (surface edges). The truck must not
operate on inclines of more than 15%.
Component 660 670 680 690
QCapacity
(1
6000 7000 8000 9000 kg
C Load centre distance 600 600 600 600 mm
Travel speed * with /
without load
22.4/22.6 22.4/22.6 22.4/22.6 22.4/22.6 km/h
Lift speed
with / without load
0.40/0.48 0.40/0.48 0.40/0.48 0.40/0.48 m/s
Lowering speed
w / w.o. load
0.60/0.48 0.60/0.36 0.60/0.36 0.60/0.36 m/s
Gradeability
(2
with / without load
27.5/30.0 27.5/30.0 26.5/30.0 23.0/27.0 %
Tow for ce
with / without load
45.6/45.6 45.6/45.6 45.6/45.6 45.6/45.6 kN
Acceleration * with /
without load to 15 m
6.0/5.0 6.0/5.0 6.0/5.0 7.0/6.0 sec
Available working
pressure
for attachments
160 160 160 160 bar
Oil flow
for attachments
80 80 80 80 l/min
