CHAPTER 1
LTE Mini-Physical Interface Module (Mini-PIM)
IN THIS CHAPTER
LTE Mini-Physical Interface Module | 2
LTE Mini-Physical Interface Module LEDs | 6
LTE Mini-Physical Interface Module Hardware Specifications | 7
LTE Mini-Physical Interface Module
The LTE Mini-Physical Interface Module (Mini-PIM) provides wireless WAN support on the SRX300 Series
and SRX550 High Memory Services Gateways. The Mini-PIM contains an integrated modem and operates
over 3G and 4G networks. The Mini-PIM supports up to two SIM cards and can be installed in any of the
Mini-PIM slots on the services gateways.
The Mini-PIM supports the following features:
•
Automatic switchover between service providers through dual SIMs
•
Storage support for multiple service provider and access point name (APN) profiles
•
LTE carrier aggregation
•
SIM lock and unlock capability
•
Always-on, dial-on-demand, and backup modes
•
Over-the-Air upgrade for modem firmware
Figure 1 on page 2 shows the front panel of the LTE Mini-PIM.
Figure 1: LTE Mini-PIM Front Panel
2
